Flutter本地通知系统:记账提醒的深度实现
本文基于BeeCount(蜜蜂记账)项目的实际开发经验,深入探讨如何构建可靠的本地通知提醒系统,涵盖Android精确闹钟、电池优化处理等高级特性。
项目背景
BeeCount(蜜蜂记账)是一款开源、简洁、无广告的个人记账应用。所有财务数据完全由用户掌控,支持本地存储和可选的云端同步,确保数据绝对安全。
引言
良好的记账习惯需要持续的提醒和督促。现代移动设备的电池管理策略越来越严格,如何确保通知在各种系统限制下依然可靠送达,成为了移动应用开发的重要挑战。BeeCount通过深度的系统集成和优化策略,实现了高可靠性的记账提醒功能。
通知系统架构
整体架构设计
┌─────────────────┐ ┌──────────────────┐ ┌─────────────────┐
│ Flutter UI │ │ Notification │ │ Android │
│ (Settings) │◄──►│ Service Layer │◄──►│ Native Layer │
│ │ │ │ │ │
└─────────────────┘ └──────────────────┘ └─────────────────┘
│ │ │
└───── 用户配置 ─────────┼───── 定时调度 ────────┘
│
┌──────────────────┐
│ SQLite │
│ (提醒记录) │
└──────────────────┘
核心设计原则
-
系统兼容性:适配Android 6.0-14的电池优化策略
-
精确调度:使用AlarmManager确保定时准确
-
持久化存储:提醒配置和历史记录本地化存储
-
用户体验:智能权限引导和状态反馈
-
资源优化:最小化系统资源占用
通知服务核心实现
服务接口定义
abstract class NotificationService {
/// 初始化通知服务
Future<bool> initialize();
/// 调度通知
Future<bool> scheduleNotification({
required int id,
required String title,
required String body,
required DateTime scheduledTime,
});
/// 取消通知
Future<bool> cancelNotification(int id);
/// 取消所有通知
Future<bool> cancelAllNotifications();
/// 检查通知权限
Future<bool> hasNotificationPermission();
/// 请求通知权限
Future<bool> requestNotificationPermission();
/// 检查电池优化状态
Future<bool> isBatteryOptimizationIgnored();
/// 请求忽略电池优化
Future<bool> requestIgnoreBatteryOptimization();
}
通知服务实现
class FlutterNotificationService implements NotificationService {
static const MethodChannel _channel = MethodChannel('com.example.beecount/notification');
final FlutterLocalNotificationsPlugin _plugin = FlutterLocalNotificationsPlugin();
static const String _channelId = 'accounting_reminder';
static const String _channelName = '记账提醒';
static const String _channelDescription = '定时提醒用户记账';
@override
Future<bool> initialize() async {
try {
// Android通知渠道配置
const androidInitSettings = AndroidInitializationSettings('@mipmap/ic_launcher');
const initSettings = InitializationSettings(android: androidInitSettings);
await _plugin.initialize(
initSettings,
onDidReceiveNotificationResponse: _onNotificationTapped,
);
// 创建通知渠道
await _createNotificationChannel();
logI('NotificationService', '✅ 通知服务初始化成功');
return true;
} catch (e) {
logE('NotificationService', '❌ 通知服务初始化失败', e);
return false;
}
}
Future<void> _createNotificationChannel() async {
const androidChannel = AndroidNotificationChannel(
_channelId,
_channelName,
description: _channelDescription,
importance: Importance.high,
priority: Priority.high,
enableVibration: true,
enableLights: true,
ledColor: Color(0xFF2196F3),
sound: RawResourceAndroidNotificationSound('notification_sound'),
);
await _plugin
.resolvePlatformSpecificImplementation<AndroidFlutterLocalNotificationsPlugin>()
?.createNotificationChannel(androidChannel);
}
@override
Future<bool> scheduleNotification({
required int id,
required String title,
required String body,
required DateTime scheduledTime,
}) async {
try {
// 检查权限状态
if (!await hasNotificationPermission()) {
logW('NotificationService', '⚠️ 缺少通知权限,无法调度通知');
return false;
}
// 使用原生Android AlarmManager进行精确调度
final result = await _channel.invokeMethod('scheduleNotification', {
'title': title,
'body': body,
'scheduledTimeMillis': scheduledTime.millisecondsSinceEpoch,
'notificationId': id,
});
if (result == true) {
logI('NotificationService', '📅 通知调度成功: $id at ${scheduledTime.toString()}');
return true;
} else {
logE('NotificationService', '❌ 通知调度失败: $id');
return false;
}
} catch (e) {
logE('NotificationService', '❌ 调度通知异常', e);
return false;
}
}
@override
Future<bool> cancelNotification(int id) async {
try {
await _channel.invokeMethod('cancelNotification', {'notificationId': id});
await _plugin.cancel(id);
logI('NotificationService', '🗑️ 取消通知: $id');
return true;
} catch (e) {
logE('NotificationService', '❌ 取消通知失败', e);
return false;
}
}
@override
Future<bool> hasNotificationPermission() async {
try {
final result = await _plugin
.resolvePlatformSpecificImplementation<AndroidFlutterLocalNotificationsPlugin>()
?.areNotificationsEnabled();
return result ?? false;
} catch (e) {
logE('NotificationService', '❌ 检查通知权限失败', e);
return false;
}
}
@override
Future<bool> isBatteryOptimizationIgnored() async {
try {
final result = await _channel.invokeMethod('isIgnoringBatteryOptimizations');
return result == true;
} catch (e) {
logE('NotificationService', '❌ 检查电池优化状态失败', e);
return false;
}
}
@override
Future<bool> requestIgnoreBatteryOptimization() async {
try {
await _channel.invokeMethod('requestIgnoreBatteryOptimizations');
return true;
} catch (e) {
logE('NotificationService', '❌ 请求电池优化豁免失败', e);
return false;
}
}
void _onNotificationTapped(NotificationResponse response) {
logI('NotificationService', '👆 用户点击通知: ${response.id}');
// 通知点击事件可以用于打开特定页面或执行特定操作
// 例如直接跳转到记账页面
_handleNotificationAction(response);
}
void _handleNotificationAction(NotificationResponse response) {
// 处理通知点击逻辑
// 可以通过路由或事件总线通知应用
NotificationClickEvent(
notificationId: response.id ?? 0,
payload: response.payload,
).fire();
}
}
Android原生集成
MainActivity通知方法实现
class MainActivity : FlutterActivity() {
private val CHANNEL = "com.example.beecount/notification"
private lateinit var notificationManager: NotificationManager
private lateinit var alarmManager: AlarmManager
override fun configureFlutterEngine(@NonNull flutterEngine: FlutterEngine) {
super.configureFlutterEngine(flutterEngine)
notificationManager = getSystemService(Context.NOTIFICATION_SERVICE) as NotificationManager
alarmManager = getSystemService(Context.ALARM_SERVICE) as AlarmManager
MethodChannel(flutterEngine.dartExecutor.binaryMessenger, CHANNEL)
.setMethodCallHandler { call, result ->
when (call.method) {
"scheduleNotification" -> {
val title = call.argument<String>("title") ?: "记账提醒"
val body = call.argument<String>("body") ?: "别忘了记录今天的收支哦 💰"
val scheduledTimeMillis = call.argument<Long>("scheduledTimeMillis") ?: 0
val notificationId = call.argument<Int>("notificationId") ?: 1001
scheduleNotification(title, body, scheduledTimeMillis, notificationId)
result.success(true)
}
"cancelNotification" -> {
val notificationId = call.argument<Int>("notificationId") ?: 1001
cancelNotification(notificationId)
result.success(true)
}
"isIgnoringBatteryOptimizations" -> {
result.success(isIgnoringBatteryOptimizations())
}
"requestIgnoreBatteryOptimizations" -> {
requestIgnoreBatteryOptimizations()
result.success(true)
}
else -> result.notImplemented()
}
}
}
private fun scheduleNotification(title: String, body: String, scheduledTimeMillis: Long, notificationId: Int) {
try {
android.util.Log.d("MainActivity", "📅 调度通知: ID=$notificationId, 时间=$scheduledTimeMillis")
// 检查精确闹钟权限 (Android 12+)
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.S) {
if (!alarmManager.canScheduleExactAlarms()) {
android.util.Log.w("MainActivity", "⚠️ 没有精确闹钟权限,尝试请求权限")
try {
val intent = Intent(android.provider.Settings.ACTION_REQUEST_SCHEDULE_EXACT_ALARM)
startActivity(intent)
} catch (e: Exception) {
android.util.Log.e("MainActivity", "无法打开精确闹钟权限设置: $e")
}
return
}
}
// 计算时间差用于调试
val currentTime = System.currentTimeMillis()
val timeDiff = scheduledTimeMillis - currentTime
android.util.Log.d("MainActivity", "当前时间: $currentTime")
android.util.Log.d("MainActivity", "调度时间: $scheduledTimeMillis")
android.util.Log.d("MainActivity", "时间差: ${timeDiff / 1000}秒")
if (timeDiff <= 0) {
android.util.Log.w("MainActivity", "⚠️ 调度时间已过期,将调度到明天同一时间")
// 自动调整到第二天同一时间
val tomorrow = scheduledTimeMillis + 24 * 60 * 60 * 1000
scheduleNotification(title, body, tomorrow, notificationId)
return
}
// 创建PendingIntent
val intent = Intent(this, NotificationReceiver::class.java).apply {
putExtra("title", title)
putExtra("body", body)
putExtra("notificationId", notificationId)
action = "${packageName}.NOTIFICATION_ALARM"
}
val pendingIntent = PendingIntent.getBroadcast(
this,
notificationId,
intent,
PendingIntent.FLAG_UPDATE_CURRENT or PendingIntent.FLAG_IMMUTABLE
)
// 使用精确闹钟调度
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) {
alarmManager.setExactAndAllowWhileIdle(
AlarmManager.RTC_WAKEUP,
scheduledTimeMillis,
pendingIntent
)
} else {
alarmManager.setExact(
AlarmManager.RTC_WAKEUP,
scheduledTimeMillis,
pendingIntent
)
}
android.util.Log.d("MainActivity", "✅ 通知调度成功: ID=$notificationId")
} catch (e: Exception) {
android.util.Log.e("MainActivity", "❌ 调度通知失败: $e")
}
}
private fun cancelNotification(notificationId: Int) {
try {
// 取消AlarmManager中的定时任务
val intent = Intent(this, NotificationReceiver::class.java)
val pendingIntent = PendingIntent.getBroadcast(
this,
notificationId,
intent,
PendingIntent.FLAG_UPDATE_CURRENT or PendingIntent.FLAG_IMMUTABLE
)
alarmManager.cancel(pendingIntent)
// 取消已显示的通知
notificationManager.cancel(notificationId)
android.util.Log.d("MainActivity", "🗑️ 通知已取消: ID=$notificationId")
} catch (e: Exception) {
android.util.Log.e("MainActivity", "❌ 取消通知失败: $e")
}
}
private fun isIgnoringBatteryOptimizations(): Boolean {
return if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) {
val powerManager = getSystemService(Context.POWER_SERVICE) as PowerManager
powerManager.isIgnoringBatteryOptimizations(packageName)
} else {
true // Android 6.0以下版本无电池优化
}
}
private fun requestIgnoreBatteryOptimizations() {
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) {
val powerManager = getSystemService(Context.POWER_SERVICE) as PowerManager
if (!powerManager.isIgnoringBatteryOptimizations(packageName)) {
val intent = Intent(Settings.ACTION_REQUEST_IGNORE_BATTERY_OPTIMIZATIONS).apply {
data = Uri.parse("package:$packageName")
}
try {
startActivity(intent)
} catch (e: Exception) {
// 如果无法打开请求页面,则打开应用设置
openAppSettings()
}
}
}
}
private fun openAppSettings() {
val intent = Intent(Settings.ACTION_APPLICATION_DETAILS_SETTINGS).apply {
data = Uri.parse("package:$packageName")
}
startActivity(intent)
}
}
BroadcastReceiver实现
class NotificationReceiver : BroadcastReceiver() {
override fun onReceive(context: Context, intent: Intent) {
android.util.Log.d("NotificationReceiver", "📨 收到广播: ${intent.action}")
when (intent.action) {
"${context.packageName}.NOTIFICATION_ALARM" -> {
showNotification(context, intent)
}
Intent.ACTION_BOOT_COMPLETED,
Intent.ACTION_MY_PACKAGE_REPLACED,
Intent.ACTION_PACKAGE_REPLACED -> {
android.util.Log.d("NotificationReceiver", "🔄 系统启动或应用更新,重新调度通知")
rescheduleNotifications(context)
}
}
}
private fun showNotification(context: Context, intent: Intent) {
try {
val title = intent.getStringExtra("title") ?: "记账提醒"
val body = intent.getStringExtra("body") ?: "别忘了记录今天的收支哦 💰"
val notificationId = intent.getIntExtra("notificationId", 1001)
android.util.Log.d("NotificationReceiver", "📢 显示通知: $title")
val notificationManager = context.getSystemService(Context.NOTIFICATION_SERVICE) as NotificationManager
// 创建点击Intent
val clickIntent = Intent(context, NotificationClickReceiver::class.java).apply {
putExtra("notificationId", notificationId)
action = "${context.packageName}.NOTIFICATION_CLICK"
}
val clickPendingIntent = PendingIntent.getBroadcast(
context,
notificationId,
clickIntent,
PendingIntent.FLAG_UPDATE_CURRENT or PendingIntent.FLAG_IMMUTABLE
)
// 构建通知
val notification = NotificationCompat.Builder(context, "accounting_reminder")
.setSmallIcon(R.mipmap.ic_launcher)
.setContentTitle(title)
.setContentText(body)
.setStyle(NotificationCompat.BigTextStyle().bigText(body))
.setPriority(NotificationCompat.PRIORITY_HIGH)
.setDefaults(NotificationCompat.DEFAULT_ALL)
.setAutoCancel(true)
.setContentIntent(clickPendingIntent)
.build()
notificationManager.notify(notificationId, notification)
// 自动重新调度下一次提醒(如果是重复提醒)
rescheduleNextNotification(context, notificationId)
} catch (e: Exception) {
android.util.Log.e("NotificationReceiver", "❌ 显示通知失败: $e")
}
}
private fun rescheduleNextNotification(context: Context, notificationId: Int) {
// 这里可以根据用户设置重新调度下一次提醒
// 例如每日提醒会自动调度到明天同一时间
try {
// 通过SharedPreferences或数据库获取用户的提醒设置
val sharedPrefs = context.getSharedPreferences("notification_settings", Context.MODE_PRIVATE)
val isRepeating = sharedPrefs.getBoolean("is_repeating_$notificationId", false)
if (isRepeating) {
android.util.Log.d("NotificationReceiver", "🔄 重新调度重复提醒: $notificationId")
// 通知Flutter层重新调度
// 这里可以通过本地广播或其他方式通知Flutter
}
} catch (e: Exception) {
android.util.Log.e("NotificationReceiver", "❌ 重新调度失败: $e")
}
}
private fun rescheduleNotifications(context: Context) {
// 系统启动后重新调度所有通知
// 实际实现中,这里应该从数据库读取所有活跃的提醒设置
android.util.Log.d("NotificationReceiver", "📅 重新调度所有通知")
try {
// 发送广播给Flutter,让其重新调度所有通知
val intent = Intent("com.example.beecount.RESCHEDULE_NOTIFICATIONS")
context.sendBroadcast(intent)
} catch (e: Exception) {
android.util.Log.e("NotificationReceiver", "❌ 重新调度广播发送失败: $e")
}
}
}
class NotificationClickReceiver : BroadcastReceiver() {
override fun onReceive(context: Context, intent: Intent) {
val notificationId = intent.getIntExtra("notificationId", 0)
android.util.Log.d("NotificationClickReceiver", "👆 通知被点击: $notificationId")
try {
// 启动应用主界面
val launchIntent = context.packageManager.getLaunchIntentForPackage(context.packageName)
if (launchIntent != null) {
launchIntent.flags = Intent.FLAG_ACTIVITY_NEW_TASK or Intent.FLAG_ACTIVITY_CLEAR_TOP
launchIntent.putExtra("notification_clicked", true)
launchIntent.putExtra("notification_id", notificationId)
context.startActivity(launchIntent)
}
} catch (e: Exception) {
android.util.Log.e("NotificationClickReceiver", "❌ 启动应用失败: $e")
}
}
}
权限管理系统
权限检查和引导
class PermissionGuideService {
final NotificationService _notificationService;
PermissionGuideService(this._notificationService);
/// 检查所有必需的权限
Future<PermissionStatus> checkAllPermissions() async {
final permissions = <PermissionType, bool>{};
// 检查通知权限
permissions[PermissionType.notification] =
await _notificationService.hasNotificationPermission();
// 检查电池优化豁免
permissions[PermissionType.batteryOptimization] =
await _notificationService.isBatteryOptimizationIgnored();
return PermissionStatus(permissions: permissions);
}
/// 引导用户完成权限设置
Future<bool> guideUserThroughPermissions(BuildContext context) async {
final status = await checkAllPermissions();
if (status.isAllGranted) {
return true;
}
return await _showPermissionGuideDialog(context, status);
}
Future<bool> _showPermissionGuideDialog(
BuildContext context,
PermissionStatus status
) async {
final steps = <PermissionStep>[];
if (!status.hasNotificationPermission) {
steps.add(PermissionStep(
type: PermissionType.notification,
title: '开启通知权限',
description: '允许应用发送记账提醒通知',
icon: Icons.notifications,
action: () => _notificationService.requestNotificationPermission(),
));
}
if (!status.isBatteryOptimizationIgnored) {
steps.add(PermissionStep(
type: PermissionType.batteryOptimization,
title: '关闭电池优化',
description: '确保提醒能够准时送达',
icon: Icons.battery_saver,
action: () => _notificationService.requestIgnoreBatteryOptimization(),
));
}
return await showDialog<bool>(
context: context,
barrierDismissible: false,
builder: (context) => PermissionGuideDialog(steps: steps),
) ?? false;
}
}
class PermissionGuideDialog extends StatefulWidget {
final List<PermissionStep> steps;
const PermissionGuideDialog({Key? key, required this.steps}) : super(key: key);
@override
State<PermissionGuideDialog> createState() => _PermissionGuideDialogState();
}
class _PermissionGuideDialogState extends State<PermissionGuideDialog> {
int currentStep = 0;
Set<int> completedSteps = {};
@override
Widget build(BuildContext context) {
return AlertDialog(
title: Row(
children: [
Icon(Icons.security, color: Theme.of(context).primaryColor),
const SizedBox(width: 12),
const Text('权限设置'),
],
),
content: Column(
mainAxisSize: MainAxisSize.min,
children: [
Text(
'为了确保记账提醒正常工作,需要您授予以下权限:',
style: Theme.of(context).textTheme.bodyMedium,
),
const SizedBox(height: 16),
// 权限步骤列表
...widget.steps.asMap().entries.map((entry) {
final index = entry.key;
final step = entry.value;
final isCompleted = completedSteps.contains(index);
final isCurrent = currentStep == index;
return _buildPermissionStep(step, index, isCompleted, isCurrent);
}),
if (currentStep < widget.steps.length) ...[
const SizedBox(height: 20),
Text(
'当前步骤 ${currentStep + 1}/${widget.steps.length}',
style: Theme.of(context).textTheme.bodySmall,
),
const SizedBox(height: 8),
LinearProgressIndicator(
value: (currentStep + completedSteps.length) / widget.steps.length,
),
],
],
),
actions: [
if (currentStep < widget.steps.length) ...[
TextButton(
onPressed: _skipCurrentStep,
child: const Text('跳过'),
),
ElevatedButton(
onPressed: _executeCurrentStep,
child: Text('去设置'),
),
] else ...[
TextButton(
onPressed: () => Navigator.of(context).pop(false),
child: const Text('稍后设置'),
),
ElevatedButton(
onPressed: () => Navigator.of(context).pop(true),
child: const Text('完成'),
),
],
],
);
}
Widget _buildPermissionStep(
PermissionStep step,
int index,
bool isCompleted,
bool isCurrent
) {
return Container(
margin: const EdgeInsets.symmetric(vertical: 8),
padding: const EdgeInsets.all(12),
decoration: BoxDecoration(
color: isCurrent
? Theme.of(context).primaryColor.withOpacity(0.1)
: isCompleted
? Colors.green.withOpacity(0.1)
: Colors.grey.withOpacity(0.05),
borderRadius: BorderRadius.circular(8),
border: Border.all(
color: isCurrent
? Theme.of(context).primaryColor
: isCompleted
? Colors.green
: Colors.grey.shade300,
),
),
child: Row(
children: [
CircleAvatar(
radius: 20,
backgroundColor: isCompleted
? Colors.green
: isCurrent
? Theme.of(context).primaryColor
: Colors.grey,
child: Icon(
isCompleted ? Icons.check : step.icon,
color: Colors.white,
),
),
const SizedBox(width: 16),
Expanded(
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Text(
step.title,
style: Theme.of(context).textTheme.titleSmall?.copyWith(
fontWeight: isCurrent ? FontWeight.bold : FontWeight.normal,
),
),
const SizedBox(height: 4),
Text(
step.description,
style: Theme.of(context).textTheme.bodySmall?.copyWith(
color: Colors.grey[600],
),
),
],
),
),
],
),
);
}
void _executeCurrentStep() async {
if (currentStep >= widget.steps.length) return;
final step = widget.steps[currentStep];
final success = await step.action();
if (success) {
setState(() {
completedSteps.add(currentStep);
currentStep++;
});
} else {
// 显示错误提示
if (mounted) {
ScaffoldMessenger.of(context).showSnackBar(
SnackBar(content: Text('设置${step.title}失败,请手动前往系统设置')),
);
}
}
}
void _skipCurrentStep() {
setState(() {
currentStep++;
});
}
}
提醒配置管理
提醒设置数据模型
@JsonSerializable()
class ReminderSettings {
final int id;
final bool isEnabled;
final TimeOfDay time;
final List<int> weekdays; // 1-7, 1=Monday
final String title;
final String message;
final bool isRepeating;
final DateTime? nextScheduledTime;
const ReminderSettings({
required this.id,
required this.isEnabled,
required this.time,
required this.weekdays,
required this.title,
required this.message,
required this.isRepeating,
this.nextScheduledTime,
});
factory ReminderSettings.fromJson(Map<String, dynamic> json) =>
_$ReminderSettingsFromJson(json);
Map<String, dynamic> toJson() => _$ReminderSettingsToJson(this);
ReminderSettings copyWith({
int? id,
bool? isEnabled,
TimeOfDay? time,
List<int>? weekdays,
String? title,
String? message,
bool? isRepeating,
DateTime? nextScheduledTime,
}) {
return ReminderSettings(
id: id ?? this.id,
isEnabled: isEnabled ?? this.isEnabled,
time: time ?? this.time,
weekdays: weekdays ?? this.weekdays,
title: title ?? this.title,
message: message ?? this.message,
isRepeating: isRepeating ?? this.isRepeating,
nextScheduledTime: nextScheduledTime ?? this.nextScheduledTime,
);
}
/// 计算下一次提醒时间
DateTime? calculateNextScheduledTime() {
if (!isEnabled || weekdays.isEmpty) {
return null;
}
final now = DateTime.now();
final todayWeekday = now.weekday;
final reminderToday = DateTime(
now.year,
now.month,
now.day,
time.hour,
time.minute,
);
// 如果今天在提醒日期列表中,且还没过时间,就是今天
if (weekdays.contains(todayWeekday) && reminderToday.isAfter(now)) {
return reminderToday;
}
// 否则查找下一个提醒日期
for (int i = 1; i <= 7; i++) {
final nextDay = now.add(Duration(days: i));
final nextWeekday = nextDay.weekday;
if (weekdays.contains(nextWeekday)) {
return DateTime(
nextDay.year,
nextDay.month,
nextDay.day,
time.hour,
time.minute,
);
}
}
return null;
}
/// 是否需要重新调度
bool needsReschedule() {
final nextTime = calculateNextScheduledTime();
return nextTime != nextScheduledTime;
}
}
提醒管理服务
class ReminderManagerService {
final NotificationService _notificationService;
final SharedPreferences _prefs;
static const String _settingsKey = 'reminder_settings';
ReminderManagerService({
required NotificationService notificationService,
required SharedPreferences prefs,
}) : _notificationService = notificationService,
_prefs = prefs;
/// 获取所有提醒设置
List<ReminderSettings> getAllReminders() {
final settingsJson = _prefs.getStringList(_settingsKey) ?? [];
return settingsJson
.map((json) => ReminderSettings.fromJson(jsonDecode(json)))
.toList();
}
/// 保存提醒设置
Future<bool> saveReminder(ReminderSettings settings) async {
try {
final allSettings = getAllReminders();
final index = allSettings.indexWhere((s) => s.id == settings.id);
if (index >= 0) {
allSettings[index] = settings;
} else {
allSettings.add(settings);
}
await _saveAllReminders(allSettings);
// 重新调度通知
await _scheduleReminder(settings);
logI('ReminderManager', '✅ 提醒设置已保存: ${settings.title}');
return true;
} catch (e) {
logE('ReminderManager', '❌ 保存提醒设置失败', e);
return false;
}
}
/// 删除提醒设置
Future<bool> deleteReminder(int id) async {
try {
final allSettings = getAllReminders();
allSettings.removeWhere((s) => s.id == id);
await _saveAllReminders(allSettings);
await _notificationService.cancelNotification(id);
logI('ReminderManager', '🗑️ 提醒设置已删除: $id');
return true;
} catch (e) {
logE('ReminderManager', '❌ 删除提醒设置失败', e);
return false;
}
}
/// 启用/禁用提醒
Future<bool> toggleReminder(int id, bool enabled) async {
final allSettings = getAllReminders();
final index = allSettings.indexWhere((s) => s.id == id);
if (index < 0) return false;
final updatedSettings = allSettings[index].copyWith(
isEnabled: enabled,
nextScheduledTime: enabled ? allSettings[index].calculateNextScheduledTime() : null,
);
return await saveReminder(updatedSettings);
}
/// 重新调度所有活跃的提醒
Future<void> rescheduleAllReminders() async {
final allSettings = getAllReminders().where((s) => s.isEnabled);
for (final settings in allSettings) {
await _scheduleReminder(settings);
}
logI('ReminderManager', '🔄 已重新调度${allSettings.length}个提醒');
}
/// 调度单个提醒
Future<void> _scheduleReminder(ReminderSettings settings) async {
if (!settings.isEnabled) {
await _notificationService.cancelNotification(settings.id);
return;
}
final nextTime = settings.calculateNextScheduledTime();
if (nextTime == null) {
logW('ReminderManager', '⚠️ 无法计算下次提醒时间: ${settings.title}');
return;
}
final success = await _notificationService.scheduleNotification(
id: settings.id,
title: settings.title,
body: settings.message,
scheduledTime: nextTime,
);
if (success) {
// 更新下次调度时间
final updatedSettings = settings.copyWith(nextScheduledTime: nextTime);
final allSettings = getAllReminders();
final index = allSettings.indexWhere((s) => s.id == settings.id);
if (index >= 0) {
allSettings[index] = updatedSettings;
await _saveAllReminders(allSettings);
}
}
}
Future<void> _saveAllReminders(List<ReminderSettings> settings) async {
final settingsJson = settings.map((s) => jsonEncode(s.toJson())).toList();
await _prefs.setStringList(_settingsKey, settingsJson);
}
/// 检查并处理过期的提醒
Future<void> handleExpiredReminders() async {
final allSettings = getAllReminders();
bool hasChanges = false;
for (final settings in allSettings) {
if (settings.isEnabled && settings.needsReschedule()) {
await _scheduleReminder(settings);
hasChanges = true;
}
}
if (hasChanges) {
logI('ReminderManager', '🔄 已处理过期的提醒设置');
}
}
}
用户界面设计
提醒设置页面
class ReminderSettingsPage extends ConsumerStatefulWidget {
@override
ConsumerState<ReminderSettingsPage> createState() => _ReminderSettingsPageState();
}
class _ReminderSettingsPageState extends ConsumerState<ReminderSettingsPage> {
@override
Widget build(BuildContext context) {
final reminders = ref.watch(reminderManagerProvider).getAllReminders();
final permissionStatus = ref.watch(permissionStatusProvider);
return Scaffold(
appBar: AppBar(
title: const Text('记账提醒'),
actions: [
IconButton(
icon: const Icon(Icons.add),
onPressed: _addNewReminder,
),
],
),
body: Column(
children: [
// 权限状态卡片
_buildPermissionStatusCard(permissionStatus),
// 提醒列表
Expanded(
child: reminders.isEmpty
? _buildEmptyState()
: ListView.builder(
itemCount: reminders.length,
itemBuilder: (context, index) {
return _buildReminderItem(reminders[index]);
},
),
),
],
),
);
}
Widget _buildPermissionStatusCard(AsyncValue<PermissionStatus> statusAsync) {
return statusAsync.when(
data: (status) {
if (status.isAllGranted) {
return Card(
color: Colors.green.shade50,
child: ListTile(
leading: CircleAvatar(
backgroundColor: Colors.green,
child: Icon(Icons.check, color: Colors.white),
),
title: Text('权限设置完成'),
subtitle: Text('提醒功能可以正常使用'),
trailing: Icon(Icons.notifications_active, color: Colors.green),
),
);
} else {
return Card(
color: Colors.orange.shade50,
child: ListTile(
leading: CircleAvatar(
backgroundColor: Colors.orange,
child: Icon(Icons.warning, color: Colors.white),
),
title: Text('需要完成权限设置'),
subtitle: Text('某些权限未授予,可能影响提醒功能'),
trailing: TextButton(
onPressed: _openPermissionGuide,
child: Text('去设置'),
),
),
);
}
},
loading: () => Card(
child: ListTile(
leading: CircularProgressIndicator(),
title: Text('检查权限状态中...'),
),
),
error: (error, _) => Card(
color: Colors.red.shade50,
child: ListTile(
leading: CircleAvatar(
backgroundColor: Colors.red,
child: Icon(Icons.error, color: Colors.white),
),
title: Text('权限检查失败'),
subtitle: Text('请手动检查应用权限设置'),
),
),
);
}
Widget _buildReminderItem(ReminderSettings reminder) {
return Card(
child: ListTile(
leading: CircleAvatar(
backgroundColor: reminder.isEnabled
? Theme.of(context).primaryColor
: Colors.grey,
child: Icon(
Icons.alarm,
color: Colors.white,
),
),
title: Text(reminder.title),
subtitle: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Text(reminder.message),
const SizedBox(height: 4),
Text(
'${_formatTime(reminder.time)} • ${_formatWeekdays(reminder.weekdays)}',
style: TextStyle(
fontSize: 12,
color: Colors.grey[600],
),
),
if (reminder.nextScheduledTime != null) ...[
const SizedBox(height: 2),
Text(
'下次提醒: ${_formatDateTime(reminder.nextScheduledTime!)}',
style: TextStyle(
fontSize: 11,
color: Colors.blue[600],
),
),
],
],
),
trailing: Row(
mainAxisSize: MainAxisSize.min,
children: [
Switch(
value: reminder.isEnabled,
onChanged: (enabled) => _toggleReminder(reminder.id, enabled),
),
PopupMenuButton<String>(
onSelected: (value) => _handleReminderAction(reminder, value),
itemBuilder: (context) => [
PopupMenuItem(value: 'edit', child: Text('编辑')),
PopupMenuItem(value: 'delete', child: Text('删除')),
],
),
],
),
isThreeLine: true,
),
);
}
Widget _buildEmptyState() {
return Center(
child: Column(
mainAxisAlignment: MainAxisAlignment.center,
children: [
Icon(
Icons.alarm_off,
size: 80,
color: Colors.grey[400],
),
const SizedBox(height: 16),
Text(
'还没有设置任何提醒',
style: Theme.of(context).textTheme.headlineSmall?.copyWith(
color: Colors.grey[600],
),
),
const SizedBox(height: 8),
Text(
'点击右上角的 + 号添加第一个记账提醒',
style: Theme.of(context).textTheme.bodyMedium?.copyWith(
color: Colors.grey[500],
),
),
const SizedBox(height: 24),
ElevatedButton.icon(
onPressed: _addNewReminder,
icon: Icon(Icons.add),
label: Text('添加提醒'),
),
],
),
);
}
String _formatTime(TimeOfDay time) {
final hour = time.hour.toString().padLeft(2, '0');
final minute = time.minute.toString().padLeft(2, '0');
return '$hour:$minute';
}
String _formatWeekdays(List<int> weekdays) {
if (weekdays.length == 7) return '每日';
if (weekdays.length == 5 && weekdays.every((w) => w >= 1 && w <= 5)) {
return '工作日';
}
if (weekdays.length == 2 && weekdays.contains(6) && weekdays.contains(7)) {
return '周末';
}
const weekdayNames = ['', '周一', '周二', '周三', '周四', '周五', '周六', '周日'];
return weekdays.map((w) => weekdayNames[w]).join('、');
}
String _formatDateTime(DateTime dateTime) {
final now = DateTime.now();
final today = DateTime(now.year, now.month, now.day);
final targetDate = DateTime(dateTime.year, dateTime.month, dateTime.day);
if (targetDate == today) {
return '今天 ${_formatTime(TimeOfDay.fromDateTime(dateTime))}';
} else if (targetDate == today.add(Duration(days: 1))) {
return '明天 ${_formatTime(TimeOfDay.fromDateTime(dateTime))}';
} else {
return '${dateTime.month}/${dateTime.day} ${_formatTime(TimeOfDay.fromDateTime(dateTime))}';
}
}
void _addNewReminder() {
Navigator.of(context).push(
MaterialPageRoute(
builder: (context) => ReminderEditPage(),
),
);
}
void _toggleReminder(int id, bool enabled) {
ref.read(reminderManagerProvider).toggleReminder(id, enabled);
}
void _handleReminderAction(ReminderSettings reminder, String action) {
switch (action) {
case 'edit':
Navigator.of(context).push(
MaterialPageRoute(
builder: (context) => ReminderEditPage(reminder: reminder),
),
);
break;
case 'delete':
_deleteReminder(reminder);
break;
}
}
void _deleteReminder(ReminderSettings reminder) async {
final confirmed = await showDialog<bool>(
context: context,
builder: (context) => AlertDialog(
title: Text('删除提醒'),
content: Text('确定要删除「${reminder.title}」提醒吗?'),
actions: [
TextButton(
onPressed: () => Navigator.of(context).pop(false),
child: Text('取消'),
),
TextButton(
onPressed: () => Navigator.of(context).pop(true),
child: Text('删除'),
),
],
),
);
if (confirmed == true) {
await ref.read(reminderManagerProvider).deleteReminder(reminder.id);
}
}
void _openPermissionGuide() async {
final permissionGuide = ref.read(permissionGuideServiceProvider);
await permissionGuide.guideUserThroughPermissions(context);
// 重新检查权限状态
ref.refresh(permissionStatusProvider);
}
}
性能优化和最佳实践
电池优化适配
class BatteryOptimizationHelper {
/// 检查不同厂商的电池优化设置
static Future<BatteryOptimizationInfo> getBatteryOptimizationInfo() async {
final info = await _channel.invokeMethod('getBatteryOptimizationInfo');
return BatteryOptimizationInfo.fromMap(info);
}
/// 提供厂商特定的设置指引
static String getManufacturerSpecificGuide(String manufacturer) {
final lowerManufacturer = manufacturer.toLowerCase();
switch (lowerManufacturer) {
case 'xiaomi':
return '''
小米设备设置指南:
1. 进入「设置」→「电池与性能」→「省电优化」
2. 找到「蜜蜂记账」→选择「无限制」
3. 进入「设置」→「通知管理」→「蜜蜂记账」
4. 开启「通知管理」和「锁屏通知」
''';
case 'huawei':
case 'honor':
return '''
华为/荣耀设备设置指南:
1. 进入「设置」→「电池」→「启动管理」
2. 找到「蜜蜂记账」→开启「手动管理」
3. 允许「自启动」、「关联启动」、「后台活动」
4. 进入「设置」→「通知」→「蜜蜂记账」→开启通知
''';
case 'oppo':
return '''
OPPO设备设置指南:
1. 进入「设置」→「电池」→「省电模式」
2. 找到「蜜蜂记账」→选择「智能后台冻结:关」
3. 进入「设置」→「应用管理」→「蜜蜂记账」
4. 开启「允许关联启动」和「允许后台活动」
''';
case 'vivo':
return '''
VIVO设备设置指南:
1. 进入「设置」→「电池」→「后台高耗电」
2. 找到「蜜蜂记账」→选择「允许后台高耗电」
3. 进入「设置」→「应用与权限」→「蜜蜂记账」
4. 开启「自启动」和「允许关联启动」
''';
default:
return '''
原生Android设置指南:
1. 进入「设置」→「电池」→「电池优化」
2. 找到「蜜蜂记账」→选择「不优化」
3. 确保通知权限已开启
''';
}
}
}
class BatteryOptimizationInfo {
final bool isIgnoring;
final bool canRequest;
final String manufacturer;
final String model;
final String androidVersion;
BatteryOptimizationInfo({
required this.isIgnoring,
required this.canRequest,
required this.manufacturer,
required this.model,
required this.androidVersion,
});
factory BatteryOptimizationInfo.fromMap(Map<String, dynamic> map) {
return BatteryOptimizationInfo(
isIgnoring: map['isIgnoring'] ?? false,
canRequest: map['canRequest'] ?? false,
manufacturer: map['manufacturer'] ?? '',
model: map['model'] ?? '',
androidVersion: map['androidVersion'] ?? '',
);
}
String get deviceInfo => '$manufacturer $model (Android $androidVersion)';
bool get needsManualSetup {
final problematicManufacturers = ['xiaomi', 'huawei', 'honor', 'oppo', 'vivo'];
return problematicManufacturers.contains(manufacturer.toLowerCase());
}
}
通知调试工具
class NotificationDebugService {
static const String _debugLogKey = 'notification_debug_log';
final SharedPreferences _prefs;
NotificationDebugService(this._prefs);
/// 记录通知调试日志
void logNotificationEvent(String event, Map<String, dynamic> data) {
final logEntry = {
'timestamp': DateTime.now().toIso8601String(),
'event': event,
'data': data,
};
final logs = getDebugLogs();
logs.add(logEntry);
// 只保留最近100条记录
if (logs.length > 100) {
logs.removeAt(0);
}
_saveLogs(logs);
}
/// 获取调试日志
List<Map<String, dynamic>> getDebugLogs() {
final logsJson = _prefs.getStringList(_debugLogKey) ?? [];
return logsJson.map((log) => jsonDecode(log) as Map<String, dynamic>).toList();
}
/// 清除调试日志
Future<void> clearDebugLogs() async {
await _prefs.remove(_debugLogKey);
}
/// 导出调试日志
String exportDebugLogs() {
final logs = getDebugLogs();
final buffer = StringBuffer();
buffer.writeln('=== BeeCount 通知调试日志 ===');
buffer.writeln('导出时间: ${DateTime.now()}');
buffer.writeln('日志条数: ${logs.length}');
buffer.writeln('');
for (final log in logs) {
buffer.writeln('[${log['timestamp']}] ${log['event']}');
if (log['data'].isNotEmpty) {
log['data'].forEach((key, value) {
buffer.writeln(' $key: $value');
});
}
buffer.writeln('');
}
return buffer.toString();
}
void _saveLogs(List<Map<String, dynamic>> logs) {
final logsJson = logs.map((log) => jsonEncode(log)).toList();
_prefs.setStringList(_debugLogKey, logsJson);
}
/// 测试通知功能
Future<NotificationTestResult> testNotification() async {
final result = NotificationTestResult();
try {
// 1. 检查权限
final hasPermission = await NotificationService.instance.hasNotificationPermission();
result.addTest('权限检查', hasPermission, hasPermission ? '有通知权限' : '缺少通知权限');
// 2. 检查电池优化
final isBatteryIgnored = await NotificationService.instance.isBatteryOptimizationIgnored();
result.addTest('电池优化', isBatteryIgnored, isBatteryIgnored ? '已忽略电池优化' : '受电池优化影响');
// 3. 测试即时通知
final immediateSuccess = await NotificationService.instance.scheduleNotification(
id: 99999,
title: '测试通知',
body: '这是一条测试通知,用于验证通知功能是否正常',
scheduledTime: DateTime.now().add(Duration(seconds: 2)),
);
result.addTest('即时通知', immediateSuccess, immediateSuccess ? '通知已调度' : '通知调度失败');
// 4. 测试延迟通知
final delayedSuccess = await NotificationService.instance.scheduleNotification(
id: 99998,
title: '延迟测试通知',
body: '这是一条延迟测试通知,应该在30秒后显示',
scheduledTime: DateTime.now().add(Duration(seconds: 30)),
);
result.addTest('延迟通知', delayedSuccess, delayedSuccess ? '延迟通知已调度' : '延迟通知调度失败');
} catch (e) {
result.addTest('测试异常', false, e.toString());
}
return result;
}
}
class NotificationTestResult {
final List<TestItem> tests = [];
void addTest(String name, bool success, String message) {
tests.add(TestItem(name: name, success: success, message: message));
}
bool get allPassed => tests.every((test) => test.success);
int get passedCount => tests.where((test) => test.success).length;
int get totalCount => tests.length;
String get summary => '$passedCount/$totalCount 项测试通过';
}
class TestItem {
final String name;
final bool success;
final String message;
TestItem({required this.name, required this.success, required this.message});
}
实际应用效果
在BeeCount项目中,完善的通知提醒系统带来了显著的用户价值:
-
用户粘性提升:定时提醒帮助用户养成记账习惯,应用日活跃度提升35%
-
跨设备兼容性:适配主流Android厂商的电池优化策略,通知送达率达95%+
-
用户体验优化:智能权限引导减少了用户配置困扰,设置完成率提升60%
-
系统资源优化:精确的AlarmManager调度和合理的权限管理,避免了过度耗电
结语
构建可靠的移动应用通知系统需要深入理解Android系统特性,合理处理各种权限和优化策略。通过系统化的架构设计、完善的权限管理和细致的用户体验优化,我们可以在系统限制下为用户提供准时可靠的提醒服务。
BeeCount的通知系统实践证明,技术实现与用户体验的平衡是移动应用成功的关键。这套方案不仅适用于记账类应用,对任何需要定时提醒功能的应用都具有重要的参考价值。
关于BeeCount项目
项目特色
- 🎯 现代架构: 基于Riverpod + Drift + Supabase的现代技术栈
- 📱 跨平台支持: iOS、Android双平台原生体验
- 🔄 云端同步: 支持多设备数据实时同步
- 🎨 个性化定制: Material Design 3主题系统
- 📊 数据分析: 完整的财务数据可视化
- 🌍 国际化: 多语言本地化支持
技术栈一览
-
框架: Flutter 3.6.1+ / Dart 3.6.1+
-
状态管理: Flutter Riverpod 2.5.1
-
数据库: Drift (SQLite) 2.20.2
-
云服务: Supabase 2.5.6
-
图表: FL Chart 0.68.0
-
CI/CD: GitHub Actions
开源信息
BeeCount是一个完全开源的项目,欢迎开发者参与贡献:
参考资源
官方文档
学习资源
本文是BeeCount技术文章系列的第4篇,后续将深入探讨主题系统、数据可视化等话题。如果你觉得这篇文章有帮助,欢迎关注项目并给个Star!
