本文详细介绍了一个完整的 Flutter UI 组件库的设计思路、架构实现和核心特性，包含 50+ 个高质量组件，支持主题切换、响应式设计等企业级功能。
📋 目录
🎯 项目概述
Flutter UI Components 是一个基于 Flutter 框架开发的企业级 UI 组件库，旨在为开发者提供一套完整、可定制、高性能的 UI 组件解决方案。
核心特性
- 🎨 完整的主题系统：支持浅色/深色主题切换，自动适配系统主题
- 📱 响应式设计：适配不同屏幕尺寸，支持平板和桌面端
- 🔧 高度可定制：丰富的配置选项，满足各种设计需求
- ⚡ 性能优化：使用 const 构造函数，减少不必要的重建
- 🧪 完整测试：单元测试和 Widget 测试覆盖
- 🏗️ 模块化架构：清晰的目录结构，便于维护和扩展
组件统计
| 分类 |
组件数量 |
主要组件 |
| 按钮组件 |
5+ |
UIButton、UIGradientButton、UIHighlightButton |
| 卡片组件 |
3+ |
UIDefaultCard、UICollectionView |
| 导航组件 |
2+ |
UIAppBarDecorator、UISegmentedControl |
| 反馈组件 |
8+ |
UIToolTip、UIToast、UIDialog、UISnackBar |
| 数据展示 |
6+ |
UITagView、UIBadgeView、UIProgressIndicator |
| 输入组件 |
4+ |
UITextField、UICheckBox、UIDropDownButton |
| 布局组件 |
5+ |
UIListView、UIGridView、UITableView |
🏗️ 系统架构设计
整体架构图
graph TB
A[Flutter UI Components] --> B[Core Module 核心模块]
A --> C[Components Module 组件模块]
B --> D[Base Classes 基础类]
B --> E[Theme System 主题系统]
B --> F[Constants 常量定义]
B --> G[Extensions 扩展方法]
C --> H[Buttons 按钮组件]
C --> I[Cards 卡片组件]
C --> J[Navigation 导航组件]
C --> K[Feedback 反馈组件]
C --> L[Data Display 数据展示]
C --> M[Input 输入组件]
C --> N[Layout 布局组件]
D --> O[BaseWidget]
D --> P[BaseStatefulWidget]
D --> Q[UIBasePage]
E --> R[AppTheme]
E --> S[ThemeConfig]
E --> T[ThemeBuilder]
模块依赖关系
graph LR
A[Components] --> B[Core]
B --> C[Flutter Framework]
D[BaseWidget] --> E[Theme System]
D --> F[Constants]
G[UI Components] --> D
G --> H[Extensions]
I[Example App] --> A
I --> J[GetX State Management]
🔧 核心模块详解
1. 基础类设计
所有组件都继承自 BaseWidget，确保统一的接口和生命周期管理：
/// 基础Widget抽象类
/// 所有UI组件都应该继承此类，确保统一的接口和生命周期管理
abstract class BaseWidget extends StatelessWidget {
const BaseWidget({super.key});
/// 组件名称，用于调试和日志
String get widgetName;
/// 组件版本，用于版本管理
String get version => '1.0.0';
/// 是否启用调试模式
bool get enableDebug => false;
@override
Widget build(BuildContext context) {
if (enableDebug) {
debugPrint('Building $widgetName v$version');
}
return buildWidget(context);
}
/// 子类需要实现的构建方法
Widget buildWidget(BuildContext context);
/// 获取组件的主题数据
ThemeData getTheme(BuildContext context) {
return Theme.of(context);
}
/// 获取组件的主题配置
AppThemeConfig getThemeConfig(BuildContext context) {
final theme = getTheme(context);
return AppThemeConfig.fromBrightness(theme.brightness);
}
}
2. 主题系统架构
主题系统采用接口抽象和配置分离的设计模式：
/// 主题配置接口
abstract class IThemeConfig {
Color get primary;
Color get secondary;
Color get success;
Color get error;
Color get text;
Color get background;
Color get surface;
// ... 更多颜色定义
}
/// 应用主题管理类
class AppTheme {
static AppTheme? _instance;
static AppTheme get instance => _instance ??= AppTheme._();
/// 当前主题模式
ThemeMode _themeMode = ThemeMode.system;
/// 当前主题配置
IThemeConfig? _customConfig;
/// 主题配置构建器
IThemeConfig Function(Brightness brightness)? _configBuilder;
/// 获取当前主题配置
IThemeConfig get currentConfig {
if (_customConfig != null) {
return _customConfig!;
}
if (_configBuilder != null) {
final brightness = _themeMode == ThemeMode.dark
? Brightness.dark : Brightness.light;
return _configBuilder!(brightness);
}
// 返回默认配置
return _themeMode == ThemeMode.dark
? const DefaultDarkThemeConfig()
: const DefaultThemeConfig();
}
/// 切换主题模式
void switchTheme(ThemeMode mode) {
if (_themeMode != mode) {
_themeMode = mode;
_notifyThemeListeners();
}
}
}
3. 常量系统设计
统一的常量管理确保设计一致性：
/// 应用常量定义
class AppConstants {
// 间距常量
static const double spacingXs = 4.0;
static const double spacingSm = 8.0;
static const double spacingMd = 16.0;
static const double spacingLg = 24.0;
static const double spacingXl = 32.0;
// 圆角常量
static const double radiusXs = 4.0;
static const double radiusSm = 8.0;
static const double radiusMd = 12.0;
static const double radiusLg = 16.0;
// 字体大小常量
static const double fontSizeXs = 12.0;
static const double fontSizeSm = 14.0;
static const double fontSizeMd = 16.0;
static const double fontSizeLg = 18.0;
static const double fontSizeXl = 20.0;
// 动画时长常量
static const int animationDurationFast = 200;
static const int animationDurationMd = 300;
static const int animationDurationSlow = 500;
}
🎨 组件分类与实现
1. 按钮组件
按钮组件支持多种类型、尺寸和状态：
/// 按钮类型枚举
enum UIButtonType {
primary, // 主要按钮
secondary, // 次要按钮
success, // 成功按钮
warning, // 警告按钮
error, // 错误按钮
info, // 信息按钮
outline, // 轮廓按钮
text, // 文本按钮
}
/// 通用按钮组件
class UIButton extends BaseWidget {
const UIButton({
super.key,
required this.text,
this.onPressed,
this.type = UIButtonType.primary,
this.size = UIButtonSize.medium,
this.isLoading = false,
this.isDisabled = false,
this.icon,
this.fullWidth = false,
});
final String text;
final VoidCallback? onPressed;
final UIButtonType type;
final UIButtonSize size;
final bool isLoading;
final bool isDisabled;
final IconData? icon;
final bool fullWidth;
@override
String get widgetName => 'UIButton';
@override
Widget buildWidget(BuildContext context) {
final themeConfig = getThemeConfig(context);
final isEnabled = onPressed != null && !isDisabled && !isLoading;
return SizedBox(
width: fullWidth ? double.infinity : null,
child: ElevatedButton(
onPressed: isEnabled ? onPressed : null,
style: _buildButtonStyle(themeConfig),
child: _buildButtonContent(themeConfig),
),
);
}
ButtonStyle _buildButtonStyle(AppThemeConfig config) {
return ElevatedButton.styleFrom(
backgroundColor: _getBackgroundColor(config),
foregroundColor: _getForegroundColor(config),
padding: _getPadding(),
shape: RoundedRectangleBorder(
borderRadius: BorderRadius.circular(AppConstants.radiusSm),
),
elevation: type == UIButtonType.outline ? 0 : 2,
);
}
}
2. 工具提示组件
工具提示组件支持多方向显示和丰富的自定义选项：
/// 工具提示方向枚举
enum UIToolTipDirection {
up, down, left, right,
upLeft, upRight, downLeft, downRight,
}
/// 工具提示配置
class UIToolTipConfig {
const UIToolTipConfig({
this.direction = UIToolTipDirection.down,
this.distance = 8.0,
this.arrowSize = 8.0,
this.backgroundColor = Colors.black87,
this.textColor = Colors.white,
this.borderRadius = 8.0,
this.padding = const EdgeInsets.all(12.0),
this.showArrow = true,
this.animationDuration = const Duration(milliseconds: 200),
});
final UIToolTipDirection direction;
final double distance;
final double arrowSize;
final Color backgroundColor;
final Color textColor;
final double borderRadius;
final EdgeInsets padding;
final bool showArrow;
final Duration animationDuration;
}
/// 主要的工具提示组件
class UIToolTip extends StatefulWidget {
const UIToolTip({
super.key,
required this.content,
this.config = const UIToolTipConfig(),
this.controller,
required this.child,
});
final Widget content;
final UIToolTipConfig config;
final UIToolTipController? controller;
final Widget child;
@override
State<UIToolTip> createState() => _UIToolTipState();
}
3. 渐变色进度指示器
自定义绘制的渐变色圆形进度指示器：
/// 渐变色圆形进度指示器组件
class UIGradientCircularProgressIndicator extends StatelessWidget {
const UIGradientCircularProgressIndicator({
super.key,
required this.radius,
this.strokeWidth = 4.0,
this.colors,
this.stops,
this.strokeCapRound = false,
this.backgroundColor = const Color(0xFFEEEEEE),
this.totalAngle = 2 * pi,
this.value,
this.animationDuration = const Duration(milliseconds: 300),
this.child,
});
final double radius;
final double strokeWidth;
final List<Color>? colors;
final List<double>? stops;
final bool strokeCapRound;
final Color backgroundColor;
final double totalAngle;
final double? value;
final Duration animationDuration;
final Widget? child;
@override
Widget build(BuildContext context) {
return CustomPaint(
size: Size(radius * 2, radius * 2),
painter: _GradientCircularProgressPainter(
strokeWidth: strokeWidth,
colors: colors ?? [Theme.of(context).primaryColor],
stops: stops,
strokeCapRound: strokeCapRound,
backgroundColor: backgroundColor,
totalAngle: totalAngle,
value: value,
),
child: child,
);
}
}
class _GradientCircularProgressPainter extends CustomPainter {
_GradientCircularProgressPainter({
required this.strokeWidth,
required this.colors,
this.stops,
required this.strokeCapRound,
required this.backgroundColor,
required this.totalAngle,
this.value,
});
final double strokeWidth;
final List<Color> colors;
final List<double>? stops;
final bool strokeCapRound;
final Color backgroundColor;
final double totalAngle;
final double? value;
@override
void paint(Canvas canvas, Size size) {
final center = Offset(size.width / 2, size.height / 2);
final radius = (size.width - strokeWidth) / 2;
// 绘制背景圆环
final backgroundPaint = Paint()
..color = backgroundColor
..strokeWidth = strokeWidth
..style = PaintingStyle.stroke
..strokeCap = strokeCapRound ? StrokeCap.round : StrokeCap.butt;
canvas.drawArc(
Rect.fromCircle(center: center, radius: radius),
-pi / 2,
totalAngle,
false,
backgroundPaint,
);
// 绘制进度圆环
if (value != null && value! > 0) {
final progressPaint = Paint()
..strokeWidth = strokeWidth
..style = PaintingStyle.stroke
..strokeCap = strokeCapRound ? StrokeCap.round : StrokeCap.butt;
if (colors.length == 1) {
progressPaint.color = colors.first;
} else {
final gradient = SweepGradient(
colors: colors,
stops: stops,
);
progressPaint.shader = gradient.createShader(
Rect.fromCircle(center: center, radius: radius),
);
}
canvas.drawArc(
Rect.fromCircle(center: center, radius: radius),
-pi / 2,
totalAngle * value!,
false,
progressPaint,
);
}
}
@override
bool shouldRepaint(covariant CustomPainter oldDelegate) => true;
}
🎨 主题系统设计
主题切换流程图
flowchart TD
A[用户触发主题切换] --> B[AppTheme.switchTheme]
B --> C[更新_themeMode]
C --> D[通知主题监听器]
D --> E[UI组件重新构建]
E --> F[应用新主题样式]
G[系统主题变化] --> H[监听系统主题]
H --> I[自动切换主题模式]
I --> B
J[自定义主题配置] --> K[setCustomConfig]
K --> L[更新_customConfig]
L --> D
主题配置示例
/// 自定义主题配置示例
class CustomThemeConfig implements IThemeConfig {
const CustomThemeConfig();
@override
Color get primary => const Color(0xFF6366F1); // 靛蓝色
@override
Color get secondary => const Color(0xFF8B5CF6); // 紫色
@override
Color get success => const Color(0xFF10B981); // 绿色
@override
Color get error => const Color(0xFFEF4444); // 红色
@override
Color get warning => const Color(0xFFF59E0B); // 橙色
@override
Color get info => const Color(0xFF3B82F6); // 蓝色
@override
Color get text => const Color(0xFF1F2937); // 深灰色
@override
Color get textSecondary => const Color(0xFF6B7280); // 中灰色
@override
Color get background => const Color(0xFFF9FAFB); // 浅灰色
@override
Color get surface => Colors.white;
@override
Color get divider => const Color(0xFFE5E7EB); // 分割线颜色
@override
Color get border => const Color(0xFFD1D5DB); // 边框颜色
@override
Color get disabled => const Color(0xFF9CA3AF); // 禁用颜色
@override
Color get disabledLight => const Color(0xFFF3F4F6); // 浅禁用颜色
@override
Color get tips => const Color(0xFFF59E0B); // 提示颜色
@override
Color get dialogText => const Color(0xFF1F2937); // 对话框文本
@override
Color get lightBlue => const Color(0xFFDBEAFE); // 浅蓝色
@override
Color get lighterBlue => const Color(0xFFEFF6FF); // 更浅蓝色
@override
Color get lightGray => const Color(0xFFF3F4F6); // 浅灰色
}
/// 使用自定义主题
void setupCustomTheme() {
AppTheme.instance.setCustomConfig(const CustomThemeConfig());
}
⚡ 性能优化策略
1. 组件优化
/// 使用 const 构造函数优化
class UIButton extends BaseWidget {
const UIButton({
super.key,
required this.text,
this.onPressed,
this.type = UIButtonType.primary,
this.size = UIButtonSize.medium,
this.isLoading = false,
this.isDisabled = false,
this.icon,
this.fullWidth = false,
});
// 使用 const 构造函数可以避免不必要的重建
static const UIButton primaryButton = UIButton(
text: 'Primary',
type: UIButtonType.primary,
);
}
2. 列表优化
/// 使用 ListView.builder 优化长列表
class UIListView extends StatelessWidget {
const UIListView({
super.key,
required this.itemCount,
required this.itemBuilder,
this.separatorBuilder,
this.padding,
this.physics,
});
final int itemCount;
final Widget Function(BuildContext context, int index) itemBuilder;
final Widget Function(BuildContext context, int index)? separatorBuilder;
final EdgeInsetsGeometry? padding;
final ScrollPhysics? physics;
@override
Widget build(BuildContext context) {
return ListView.separated(
padding: padding,
physics: physics,
itemCount: itemCount,
itemBuilder: itemBuilder,
separatorBuilder: separatorBuilder ?? (context, index) => const SizedBox.shrink(),
);
}
}
3. 动画优化
/// 使用 AnimationController 优化动画性能
class _UIToolTipState extends State<UIToolTip>
with TickerProviderStateMixin {
late AnimationController _animationController;
late Animation<double> _animation;
@override
void initState() {
super.initState();
_animationController = AnimationController(
duration: widget.config.animationDuration,
vsync: this,
);
_animation = CurvedAnimation(
parent: _animationController,
curve: Curves.easeInOut,
);
}
@override
void dispose() {
_animationController.dispose();
super.dispose();
}
}
🧪 测试与质量保证
1. 单元测试示例
import 'package:flutter_test/flutter_test.dart';
import 'package:flutter_ui_components/flutter_ui_components.dart';
void main() {
group('UIButton Tests', () {
testWidgets('应该渲染带有正确文本的按钮', (tester) async {
// Arrange
const buttonText = '测试按钮';
// Act
await tester.pumpWidget(
MaterialApp(
home: Scaffold(
body: UIButton(
text: buttonText,
onPressed: () {},
),
),
),
);
// Assert
expect(find.text(buttonText), findsOneWidget);
});
testWidgets('禁用状态下按钮应该不可点击', (tester) async {
// Arrange
bool wasPressed = false;
// Act
await tester.pumpWidget(
MaterialApp(
home: Scaffold(
body: UIButton(
text: '禁用按钮',
onPressed: () => wasPressed = true,
isDisabled: true,
),
),
),
);
await tester.tap(find.text('禁用按钮'));
await tester.pump();
// Assert
expect(wasPressed, false);
});
testWidgets('加载状态下应该显示加载指示器', (tester) async {
// Act
await tester.pumpWidget(
MaterialApp(
home: Scaffold(
body: UIButton(
text: '加载按钮',
onPressed: () {},
isLoading: true,
),
),
),
);
// Assert
expect(find.byType(CircularProgressIndicator), findsOneWidget);
});
});
}
2. Widget 测试示例
void main() {
group('UIToolTip Tests', () {
testWidgets('应该显示工具提示内容', (tester) async {
// Arrange
const tooltipContent = '这是一个工具提示';
// Act
await tester.pumpWidget(
MaterialApp(
home: Scaffold(
body: UIToolTip(
content: const Text(tooltipContent),
child: const Text('悬停我'),
),
),
),
);
// 触发悬停
await tester.longPress(find.text('悬停我'));
await tester.pumpAndSettle();
// Assert
expect(find.text(tooltipContent), findsOneWidget);
});
testWidgets('应该根据配置显示箭头', (tester) async {
// Act
await tester.pumpWidget(
MaterialApp(
home: Scaffold(
body: UIToolTip(
content: const Text('带箭头的提示'),
config: const UIToolTipConfig(showArrow: true),
child: const Text('悬停我'),
),
),
),
);
await tester.longPress(find.text('悬停我'));
await tester.pumpAndSettle();
// Assert
expect(find.byType(CustomPaint), findsWidgets);
});
});
}
📱 使用示例
1. 基础使用
import 'package:flutter/material.dart';
import 'package:flutter_ui_components/flutter_ui_components.dart';
class MyApp extends StatelessWidget {
@override
Widget build(BuildContext context) {
return MaterialApp(
title: 'Flutter UI Components Demo',
theme: AppTheme.instance.lightTheme,
darkTheme: AppTheme.instance.darkTheme,
themeMode: AppTheme.instance.themeMode,
home: const MyHomePage(),
);
}
}
class MyHomePage extends StatelessWidget {
const MyHomePage({super.key});
@override
Widget build(BuildContext context) {
return Scaffold(
appBar: AppBar(
title: const Text('UI Components Demo'),
actions: [
IconButton(
icon: const Icon(Icons.brightness_6),
onPressed: () {
// 切换主题
final currentMode = AppTheme.instance.themeMode;
final newMode = currentMode == ThemeMode.light
? ThemeMode.dark
: ThemeMode.light;
AppTheme.instance.switchTheme(newMode);
},
),
],
),
body: SingleChildScrollView(
padding: const EdgeInsets.all(16),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
// 按钮组件示例
_buildSectionTitle('按钮组件'),
Wrap(
spacing: 8,
runSpacing: 8,
children: [
UIButton(
text: '主要按钮',
onPressed: () => _showToast('主要按钮被点击'),
type: UIButtonType.primary,
),
UIButton(
text: '成功按钮',
onPressed: () => _showToast('成功按钮被点击'),
type: UIButtonType.success,
),
UIButton(
text: '警告按钮',
onPressed: () => _showToast('警告按钮被点击'),
type: UIButtonType.warning,
),
UIButton(
text: '错误按钮',
onPressed: () => _showToast('错误按钮被点击'),
type: UIButtonType.error,
),
UIButton(
text: '轮廓按钮',
onPressed: () => _showToast('轮廓按钮被点击'),
type: UIButtonType.outline,
),
UIButton(
text: '文本按钮',
onPressed: () => _showToast('文本按钮被点击'),
type: UIButtonType.text,
),
],
),
const SizedBox(height: 24),
// 卡片组件示例
_buildSectionTitle('卡片组件'),
UIDefaultCard(
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
const Text(
'卡片标题',
style: TextStyle(
fontSize: 18,
fontWeight: FontWeight.bold,
),
),
const SizedBox(height: 8),
const Text('这是一个卡片组件的示例内容。'),
const SizedBox(height: 16),
Row(
mainAxisAlignment: MainAxisAlignment.end,
children: [
UIButton(
text: '取消',
type: UIButtonType.text,
onPressed: () {},
),
const SizedBox(width: 8),
UIButton(
text: '确定',
onPressed: () {},
),
],
),
],
),
),
const SizedBox(height: 24),
// 工具提示组件示例
_buildSectionTitle('工具提示组件'),
Center(
child: UIToolTip(
content: const Text('这是一个工具提示'),
config: const UIToolTipConfig(
direction: UIToolTipDirection.down,
backgroundColor: Colors.black87,
textColor: Colors.white,
),
child: UIButton(
text: '悬停查看提示',
onPressed: () {},
),
),
),
const SizedBox(height: 24),
// 进度指示器示例
_buildSectionTitle('进度指示器'),
Center(
child: Column(
children: [
UIGradientCircularProgressIndicator(
radius: 50,
value: 0.7,
colors: const [
Colors.blue,
Colors.purple,
Colors.pink,
],
child: const Center(
child: Text(
'70%',
style: TextStyle(
fontSize: 16,
fontWeight: FontWeight.bold,
),
),
),
),
const SizedBox(height: 16),
UIProgressIndicator(
value: 0.6,
backgroundColor: Colors.grey[300]!,
valueColor: Colors.blue,
),
],
),
),
const SizedBox(height: 24),
// 标签组件示例
_buildSectionTitle('标签组件'),
Wrap(
spacing: 8,
runSpacing: 8,
children: [
UITagView(
text: '默认标签',
onTap: () => _showToast('默认标签被点击'),
),
UITagView(
text: '主要标签',
type: UITagType.primary,
onTap: () => _showToast('主要标签被点击'),
),
UITagView(
text: '成功标签',
type: UITagType.success,
onTap: () => _showToast('成功标签被点击'),
),
UITagView(
text: '警告标签',
type: UITagType.warning,
onTap: () => _showToast('警告标签被点击'),
),
UITagView(
text: '错误标签',
type: UITagType.error,
onTap: () => _showToast('错误标签被点击'),
),
],
),
],
),
),
);
}
Widget _buildSectionTitle(String title) {
return Padding(
padding: const EdgeInsets.only(bottom: 16),
child: Text(
title,
style: const TextStyle(
fontSize: 20,
fontWeight: FontWeight.bold,
),
),
);
}
void _showToast(String message) {
// 这里可以使用 UIToast 组件显示提示
debugPrint('Toast: $message');
}
}
2. 高级使用
/// 自定义主题配置
class MyCustomThemeConfig implements IThemeConfig {
const MyCustomThemeConfig();
@override
Color get primary => const Color(0xFF6366F1);
@override
Color get secondary => const Color(0xFF8B5CF6);
@override
Color get success => const Color(0xFF10B981);
@override
Color get error => const Color(0xFFEF4444);
@override
Color get warning => const Color(0xFFF59E0B);
@override
Color get info => const Color(0xFF3B82F6);
@override
Color get text => const Color(0xFF1F2937);
@override
Color get textSecondary => const Color(0xFF6B7280);
@override
Color get background => const Color(0xFFF9FAFB);
@override
Color get surface => Colors.white;
@override
Color get divider => const Color(0xFFE5E7EB);
@override
Color get border => const Color(0xFFD1D5DB);
@override
Color get disabled => const Color(0xFF9CA3AF);
@override
Color get disabledLight => const Color(0xFFF3F4F6);
@override
Color get tips => const Color(0xFFF59E0B);
@override
Color get dialogText => const Color(0xFF1F2937);
@override
Color get lightBlue => const Color(0xFFDBEAFE);
@override
Color get lighterBlue => const Color(0xFFEFF6FF);
@override
Color get lightGray => const Color(0xFFF3F4F6);
}
/// 应用初始化
void main() {
// 设置自定义主题
AppTheme.instance.setCustomConfig(const MyCustomThemeConfig());
runApp(const MyApp());
}
/// 响应式布局示例
class ResponsiveLayout extends StatelessWidget {
const ResponsiveLayout({super.key});
@override
Widget build(BuildContext context) {
return LayoutBuilder(
builder: (context, constraints) {
if (constraints.maxWidth > 1200) {
return _buildDesktopLayout();
} else if (constraints.maxWidth > 800) {
return _buildTabletLayout();
} else {
return _buildMobileLayout();
}
},
);
}
Widget _buildDesktopLayout() {
return Row(
children: [
Expanded(
flex: 2,
child: _buildSidebar(),
),
Expanded(
flex: 5,
child: _buildMainContent(),
),
Expanded(
flex: 2,
child: _buildRightPanel(),
),
],
);
}
Widget _buildTabletLayout() {
return Column(
children: [
_buildHeader(),
Expanded(
child: Row(
children: [
Expanded(
flex: 1,
child: _buildSidebar(),
),
Expanded(
flex: 2,
child: _buildMainContent(),
),
],
),
),
],
);
}
Widget _buildMobileLayout() {
return Column(
children: [
_buildHeader(),
Expanded(
child: _buildMainContent(),
),
_buildBottomNavigation(),
],
);
}
Widget _buildSidebar() {
return UIDefaultCard(
child: Column(
children: [
UIButton(
text: '菜单项 1',
type: UIButtonType.text,
fullWidth: true,
onPressed: () {},
),
UIButton(
text: '菜单项 2',
type: UIButtonType.text,
fullWidth: true,
onPressed: () {},
),
UIButton(
text: '菜单项 3',
type: UIButtonType.text,
fullWidth: true,
onPressed: () {},
),
],
),
);
}
Widget _buildMainContent() {
return UIDefaultCard(
child: Column(
children: [
const Text(
'主要内容区域',
style: TextStyle(fontSize: 24, fontWeight: FontWeight.bold),
),
const SizedBox(height: 16),
UIProgressIndicator(
value: 0.7,
backgroundColor: Colors.grey[300]!,
valueColor: Colors.blue,
),
const SizedBox(height: 16),
Wrap(
spacing: 8,
children: [
UITagView(text: '标签 1'),
UITagView(text: '标签 2', type: UITagType.primary),
UITagView(text: '标签 3', type: UITagType.success),
],
),
],
),
);
}
Widget _buildRightPanel() {
return UIDefaultCard(
child: Column(
children: [
const Text('右侧面板'),
const SizedBox(height: 16),
UIGradientCircularProgressIndicator(
radius: 30,
value: 0.8,
colors: const [Colors.blue, Colors.purple],
),
],
),
);
}
Widget _buildHeader() {
return Container(
padding: const EdgeInsets.all(16),
child: Row(
children: [
const Text(
'应用标题',
style: TextStyle(fontSize: 20, fontWeight: FontWeight.bold),
),
const Spacer(),
UIButton(
text: '设置',
type: UIButtonType.outline,
onPressed: () {},
),
],
),
);
}
Widget _buildBottomNavigation() {
return Container(
padding: const EdgeInsets.all(16),
child: Row(
mainAxisAlignment: MainAxisAlignment.spaceAround,
children: [
UIButton(
text: '首页',
type: UIButtonType.text,
onPressed: () {},
),
UIButton(
text: '搜索',
type: UIButtonType.text,
onPressed: () {},
),
UIButton(
text: '我的',
type: UIButtonType.text,
onPressed: () {},
),
],
),
);
}
}
🚀 总结与展望
项目亮点
-
完整的组件体系：覆盖了 Flutter 应用开发中的大部分 UI 需求
-
灵活的主题系统：支持浅色/深色主题切换，易于定制
-
优秀的性能表现：使用 const 构造函数和优化策略
-
完善的测试覆盖：确保组件的稳定性和可靠性
-
清晰的架构设计：模块化设计，易于维护和扩展
技术特色
-
SOLID 原则：遵循单一职责、开放封闭等设计原则
-
响应式设计：适配不同屏幕尺寸和设备类型
-
自定义绘制：部分组件使用 CustomPainter 实现复杂效果
-
动画优化：使用 AnimationController 实现流畅动画
-
状态管理：支持多种状态管理方案
未来规划
-
组件扩展：继续添加更多实用组件
-
主题丰富：提供更多预设主题方案
-
国际化支持：完善多语言支持
-
性能优化：持续优化组件性能
-
文档完善：提供更详细的开发文档
Flutter UI Components 致力于为 Flutter 开发者提供一套完整、高质量、易用的 UI 组件解决方案。通过模块化的架构设计、完善的主题系统和优秀的性能表现，帮助开发者快速构建美观、流畅的 Flutter 应用。
项目由于目前还在完善中，未来会在合适的时候更新出来，感兴趣的同学敬请期待
📚 相关资源
登录
